This instrument can be used to measuring DC voltage, AC voltage, DC current, resistance and temperature. LCD screen and digital display, reading accuracy and speediness. Stable performance, lower power consumption, higher reliability and safety.
Features:Â
2. 3 1/2 digits and Maximum Display is 1999.
3. Low battery indication and Overload protection.
4. A variety of measurement functions such as voltage, current, resistance, temperature and Transistor &Diode test.
5. The DT-830B Digital Multimeter provides an economical solution to your daily electrical and temperature measurement
Function
|
Range
|
Accuracy
|
DC Voltage
|
200mV-1000V
|
±(0.5%+2dgt)
|
AC Voltage
|
200-750V
|
±(1.2%+10dgt)
|
±(1.2%+10dgt)
|
200uA-10A
|
±(1%+2dgt)
|
Resistance
|
200Ω-2MΩ
|
±(0.8%+2dgt)
|
Specification:
Model Number: |
|
Measuring Voltage Range: |
|
Measuring Capacitance Range: | Â Â Â Â Â 10A |
Operating Temperature: |
|
Feature |
|
Measuring Current Range: |
|
Measuring Resistance Range: |
|
Measuring Inductance Range: | Â Â Â Â Â None |
Display Type: |
|
Type |
|
DT830B AC/DC LCD Digital Multimeter Components
- 1 x Multimeter
- 1 x English User Manual
- 2 x Test Lead Probe
